LED Recessed Crycle Linear Light Anti Glare OW XTD-AZ010/8-30W

Category Tags , , , , ,

Recessed Circle An-glare DIY Linear Light(8w-30w)

DIY design according to the light purpose.

Customized LED Linear Light in here,What do you want, What we can do.

Additional information

Wattage

8W,15W,20W,30W
Input Voltage

85-265V
LED Type

COB
CCT

3000K, 4500K, 6500K
ASK FOR A QUOTE

Please enjoy the product dynamic video

Product Details:

Product Features:

  • Circle Recessed DIY line light with variable modules, space lighting more flexible.
  • Its popularity also lies in its strong applicability. Different types of lighting modules can be supported in one set of models, so the application scenario is more extensive.
    Currently, there are 4 different types of lighting modules: spotlights, downlights, and track lights,linear light. which can be freely combined and matched as needed. This means that whether it is accent lighting to highlight architectural elements, overall lighting to provide basic illumination, or mood lighting to enhance the emotion of space, the requirements can be met with a set of round line DIY system luminaires.
  • Embedded products, after installation can be integrated with the ceiling, so that the use of scenes more coordinated!

Application :

  • Suitable for indoor home lighting, shopping malls, hotels, jewelry stores

Product Parameters:

LED Recessed Crycle Linear Light Anti Glare OW XTD-AZ010/8-30W

Moel Power Watt Led Voltage CRI Beam Angel Adjustable Angel Luminous/Watt Body Size Cut Size CCT Fram Color
XTDR2-A-6 8 W SMD 3030 85-265V ≥90 30°/50° NO. ≥90lm φ80*H35mm φ75mm 2700K/4500K/6500K Whtie+Black
XTDR2-A-12 15 W SMD 3030 85-265V ≥90 30°/50° NO. ≥90lm φ128*H35mm φ120mm 2700K/4500K/6500K Whtie+Black
XTDR2-A-18 20 W SMD 3030 85-265V ≥90 30°/50° NO. ≥90lm φ173*H35mm φ165mm 2700K/4500K/6500K Whtie+Black
XTDR2-A-24 30 W SMD 3030 85-265V ≥90 30°/50° NO. ≥90lm φ218*H35mm φ205mm 2700K/4500K/6500K Whtie+Black
XTDR2-B-12 8 W SMD 3030 85-265V ≥90 30°/50° NO. ≥90lm φ70.4*H35mm NO. 2700K/4500K/6500K Whtie+Black
XTDR2-B-18 15 W SMD 3030 85-265V ≥90 30°/50° NO. ≥90lm φ115.4*H35mm NO. 2700K/4500K/6500K Whtie+Black
XTDR2-B-24 20 W SMD 3030 85-265V ≥90 30°/50° NO. ≥90lm φ160.4*H35mm NO. 2700K/4500K/6500K Whtie+Black
SD-12 7 W CREE 85-265V ≥90 15°/  24°/36° 45° ≥90lm φ70.4*H56.3mm NO. 2700K/4500K/6500K Whtie+Black
SD-18 12 W CREE 85-265V ≥90 15°/  24°/36° 45° ≥90lm φ115.4*H77.2mm NO. 2700K/4500K/6500K Whtie+Black
SD-24 20 W CREE 85-265V ≥90 15°/  24°/36° 45° ≥90lm φ160.4*H101.8mm NO. 2700K/4500K/6500K Whtie+Black
TD-12 7 W SMD 2835 85-265V ≥90 NO. NO. ≥90lm φ70.4*H41.4mm NO. 2700K/4500K/6500K Whtie
TD-18 10 W SMD 2835 85-265V ≥90 NO. NO. ≥90lm φ115.4*H45.6mm NO. 2700K/4500K/6500K Whtie
TD-24 18 W SMD 2835 85-265V ≥90 NO. NO. ≥90lm φ160.4*H47.6mm NO. 2700K/4500K/6500K Whtie
GD-12 5 W CREE 85-265V ≥90 20°-50°  355° rotation and 90° tilt ≥90lm φ70.4*H19mm/φ25*H47mm NO. 2700K/4500K/6500K Whtie+Black
GD-18 8 W CREE 85-265V ≥90 20°-50°  355° rotation and 90° tilt ≥90lm φ115.4*H19mm/φ35*H74mm NO. 2700K/4500K/6500K Whtie+Black
GD-24 15 W CREE 85-265V ≥90 20°-50°  355° rotation and 90° tilt ≥90lm φ160.4*H19mm/φ55*H99mm NO. 2700K/4500K/6500K Whtie+Black
C-12 / NO. NO. NO. NO. NO. NO. NO. NO. Whtie
C-18 / NO. NO. NO. NO. NO. NO. NO. NO. Whtie
C-24 / NO. NO. NO. NO. NO. NO. NO. NO. Whtie
